Quick Draw Features

• Compact: System compacts down to 8 feet on a full length trailer.
• Versatile: Tension the front of the system without the need to walk to the back of the trailer.
• Smooth Appearance: No fasteners through the tarp panels.
• More Aluminum = More Strength: 3/16" bow thickness, 3/16" headboard plate thickness, ...no compromise.

Quick Draw Options

• Headboard Access Door : Available in 2 sizes.
• Headboard Grab Handle : Add comfort and safety to movements.
• Headboard Vents : Allows for air flow within tarp system.
• Headboard Chain Binder Bars : Up to 4 positions.
• Headboard Shelves : Up to 2 levels with options for full shelf across the top of side shelves.
• Headboard Floor Boxes : Up to 2 boxes positioned on either side behind the headboard.
• Headboard Air Lock : Lock the front bow with air cylinders.
• Headboard Wind Deflector : Increase aerodynamics.
• Headboard Light Bar : 9 lights across the top. Choose from several light sizes/styles.
• Track Light Bar : Mounted below track. Choose from several light sizes/styles.
• Interior Spotlight : Choose single or double.
• Mirror Finish Stainless Steel Wrap : Options available for headboard and light bars.
• Interior Ratcheting : Tension the system at the front from inside the trailer.
• 4 Point Lifter Bows : Better clearance over high loads.
• Custom Height : Choose an exact height for the tarp system.
• Back Flap Rope and Pulley : An alternative approach to opening the back flap.

Platform Features

• Side Rail Pockets: Choose with or without side rail pockets.
• Width: Choose 102" or 96".
• Length: Choose any custom length.
• Lighting: Lighting and wiring comform to FMVSS and CMVSS; doubled jacketed heavy duty wiring harness.
• Main Sills: 8" structural steel channel main sills (6" optionally available).
• Side Rails: 6" structural steel channel side rails with 6" formed steel rear apron.
• Cross Members: 4" structural steel channel cross members on 12" centers (3" channel optionally available).
• Floor: 1-3/8" apitong wood floor.
• ICC Bumper and Mud Flaps: Included.
• Paint Prep: All steel structures are sand blasted and primed with expoxy.
• Paint Finish: Polyester urethane enamel black paint finish.
• Welding: All welding conforms to CWB-W59 standards.
• Chassis Connection: Welded shear plates bolted to chassis frame.
• Load Capacity: Designed to meet cargo capacity as specified by chassis manufacturer.

• Light Weight: Lighter weight compared to an equivalent steel platform.
• No Rust: It's all aluminum.
• Stays Clean: Fewer places for road debris to accumulate on the underside compared with steel platforms.
• More Ways to Tie Down: J-plate tie down hook points are integrated into the aluminum side rails.
• Side Rail Pockets: Choose with or without side rail pockets.
• Width: Choose 102" or 96".
• Length: Choose any custom length.
• Lighting: Lighting and wiring comform to FMVSS and CMVSS; doubled jacketed heavy duty wiring harness.
• Main Sills: 8" aluminum box section.
• Floor: Aluminum flooring also acts as cross members.
• ICC Bumper and Mud Flaps: Included.
• Welding: All welding conforms to CWB-W59.2 standards.
• Chassis Connection: Welded shear plates bolted to chassis frame.
• Load Capacity: Designed to meet cargo capacity as specified by chassis manufacturer.

Platform Options

• Tie Downs: Sliding webbing winches.
• Tie Downs: Various nylon cargo straps.
• 4' Headboard: CNC cut diamond pattern window.
• Quick Draw Headboard: Lexan window.
• Interior Spot Lights: Installed on headboard.
• Toolboxes: Headboard and/or underbody.
• Dock Bumpers: Installed on rear apron.
• Folding Steps: One or two safety grip folding steps installed on rear.
• Fold-out Truck Steps: Pull out and fold out steps installed on rear.
• Deluxe ICC Bumper: Installed on rear.
• Lighting: Deluxe tail light boxes.
• Customize: Custom options available.
